Armored Type UC309 FJ Insert Bearing

The UC309 FJ Insert Bearing (with Eccentric Locking Collar) can be easily attached to the shaft with the grub screws or inserted in a housing.

Classification :

Armored Type

WhatsApp : +8615314156859

E-mail : jack@odqbearing.com

PRODUCT DETAILS

Keywords: Shandong Guanxian Monten Bearing Co., Ltd.

The UC309 FJ Insert Bearing (with Eccentric Locking Collar) can be easily attached to the shaft with the grub screws or inserted in a housing. It is suitable for high radial loads. Main dimensions according to DIN 626-1.

with extended inner ring and grub screws for fixing the inner ring on a shaft
suitable for mounting in a housing bearing massive series and therefore suitable for very high loads smooth running and good behavior with tilting due to the extended inner ring the spherical outer surface of the outer ring can compensate misalignment if it is installed in a corresponding housing two-piece sealing system: with sheet steel washer reinforced rubber seal inside; outside additionally with upstream slinger made of sheet steel for high mechanical protection against foreign matter lubricated for life; under normal operating conditions relubrication is not required

Typ	Shaft-Ø	Dimensions in mm							Weight
Typ	in mm	D	Bi	Be	n	m	G	ds	(kg)
UC305	25	62	38	22	15	23	6	M6X0.75	0,45
UC306	30	72	43	24	17	26	6	M6X0.75	0,56
UC307	35	80	48	26	19	29	8	M8X1	0,48
UC308	40	90	52	28	19	33	10	M10X1.25	1,0
UC309	45	100	57	30	22	35	10	M10X1.25	1,33
UC310	50	110	61	32	22	39	12	M12X1.5	1,69
UC311	55	120	66	34	25	41	12	M12X1.5	1,9
UC312	60	130	71	36	26	45	12	M12X1.5	2,6
UC313	65	140	75	38	30	45	12	M12X1.5	3,16
UC314	70	150	78	40	33	45	12	M12X1.5	3,9
UC315	75	160	82	42	32	50	14	M14X1.5	4,7
UC316	80	170	86	44	34	52	14	M14X1.5	5,6
UC317	85	180	96	46	40	56	16	M16X1.5	6,9
UC318	90	190	96	48	40	56	16	M16X1.5	7,87

Cylindrical Outer Race with Locking Collar, Light Duty, Pre Lubricated with Grease

QUALITY DETECTION

FACTORY WORKSHOP

factory

APPLICATION FIELD

FAQ

Once the products received by customer were found not comply with the products or contract demands, what will you do?

A: We will compensate the customer for all the loss without any hesitation.

Do you provide samples Is it free or extra?

A: Yes, we could offer free samples.

What certifications do your products have?

A: We have ISO 9001, SGS, EWC and other certifications.

What kind of payment terms would you accept?

A: We always do T/T.30% T/T as deposit,70% T/T as balance.

What is the delivery time?

A: 10-15 days

What is your MOQ?

A: We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.
