UCP Series Pillow Block Ball Bearings

UCP Series Pillow Block Ball Bearings units consist of an insert bearing mounted in a cast iron housing that can be bolted to a support surface

Classification :

Bearing Units

UCP

WhatsApp : +8615314156859

E-mail : jack@odqbearing.com

PRODUCT DETAILS

Keywords: Shandong Guanxian Monten Bearing Co., Ltd.

Compact structure: UCP series bearings have a compact design and are suitable for mounting in limited space.

Easy to install: Due to its self-aligning feature, the installation process is simple and quick.

High durability: Made of high-quality bearing steel, they have good durability and stability and are suitable for both normal and severe working conditions
Anti-corrosion properties: the blue-colored coating not only aesthetically pleasing, but also effectively prevents corrosion and prolongs service life

Item #	Shaft Diameter d	Dimension H	Dimension L	Dimension J	Dimension A
UCP-203	17 mm	N/A	N/A	N/A	N/A
UCP-203-11	11/16 in	N/A	N/A	N/A	N/A
UCP-204-12	3/4 in	33.3 mm	127 mm	96 mm	37 mm
UCP-204	20 mm	33.3 mm	127 mm	96 mm	37 mm
UCP-205-14	7/8 in	36.5 mm	140 mm	105 mm	38 mm
UCP-205-15	15/16 in	36.5 mm	140 mm	105 mm	38 mm
UCP-205	25 mm	36.5 mm	140 mm	105 mm	38 mm
UCP-205-16	1 in	36.5 mm	140 mm	105 mm	38 mm
UCP-206-18	1 1/2 in	42.9 mm	160 mm	121 mm	44 mm
UCP-206	30 mm	42.9 mm	160 mm	121 mm	44 mm
UCP-206-19	1 3/16 in	42.9 mm	160 mm	121 mm	44 mm
UCP-206-20	1 1/4 in	42.9 mm	160 mm	121 mm	44 mm
UCP-207-20	1 1/4 in	47.6 mm	167 mm	126 mm	48 mm
UCP-207-21	1 5/16 in	47.6 mm	167 mm	126 mm	48 mm
UCP-207-22	1 3/8 in	47.6 mm	167 mm	126 mm	48 mm
UCP-207	35 mm	47.6 mm	167 mm	126 mm	48 mm
UCP-207-23	1 7/16 in	47.6 mm	167 mm	126 mm	48 mm
UCP-208-24	1 1/2 in	49.2 mm	180 mm	136 mm	52 mm
UCP-208-25	1 9/16 in	49.2 mm	180 mm	136 mm	52 mm
UCP-208	40 mm	49.2 mm	180 mm	136 mm	52 mm
UCP-209-26	1 5/8 in	54 mm	190 mm	146 mm	54 mm
UCP-209-27	1 11/16 in	54 mm	190 mm	146 mm	54 mm
UCP-209-28	1 3/4 in	54 mm	190 mm	146 mm	54 mm
UCP-209	45 mm	54 mm	190 mm	146 mm	54 mm
UCP-210-30	1 7/8 in	57.2 mm	204 mm	159 mm	57 mm
UCP-210-31	1 15/16 in	57.2 mm	204 mm	159 mm	57 mm
UCP-210	50 mm	57.2 mm	204 mm	159 mm	57 mm
UCP-210-32	2 in	57.2 mm	204 mm	159 mm	57 mm
UCP-211-32	2 in	63.5 mm	217 mm	172 mm	60 mm
UCP-211-34	2 1/8 in	63.5 mm	217 mm	172 mm	60 mm
UCP-211	55 mm	63.5 mm	217 mm	172 mm	60 mm
UCP-211-35	2 3/16 in	63.5 mm	217 mm	172 mm	60 mm
UCP-212-36	2 1/4 in	69.9 mm	238 mm	186 mm	66 mm
UCP-212-37	2 5/16 in	69.9 mm	238 mm	186 mm	66 mm
UCP-212	60 mm	69.9 mm	238 mm	186 mm	66 mm
UCP-212-38	2 3/8 in	69.9 mm	238 mm	186 mm	66 mm
UCP-212-39	2 7/16 in	69.9 mm	238 mm	186 mm	66 mm
UCP-213-40	2 1/2 in	76.2 mm	262 mm	203 mm	70 mm
UCP-213	65 mm	76.2 mm	262 mm	203 mm	70 mm
UCP-213-43	2 11/16 in	76.2 mm	262 mm	203 mm	70 mm
UCP-214-44	2 3/4 in	79.4 mm	266 mm	210 mm	72 mm
UCP-214	70 mm	79.4 mm	266 mm	210 mm	72 mm
UCP-215-44	2 3/4 in	82.6 mm	275 mm	217 mm	74 mm
UCP-215-47	2 15/16 in	82.6 mm	275 mm	217 mm	74 mm
UCP-215	75 mm	82.6 mm	275 mm	217 mm	74 mm
UCP-215-48	3 in	82.6 mm	275 mm	217 mm	74 mm
UCP-216	80 mm	88.9 mm	292 mm	232 mm	78 mm
UCP-216-52	3 1/4 in	88.9 mm	292 mm	232 mm	78 mm
UCP-217-52	3 1/4 in	95.2 mm	310 mm	247 mm	83 mm
UCP-217	85 mm	95.2 mm	310 mm	247 mm	83 mm
UCP-218-56	3 1/2 in	101.6 mm	327 mm	262 mm	88 mm
UCP-218	90 mm	101.6 mm	327 mm	262 mm	88 mm

Product Overview

UCP Series Pillow Block Ball Bearings units consist of an insert bearing mounted in a cast iron housing that can be bolted to a support surface. This variant is strong and stiff, and is suitable for applications with both constant and alternating directions of rotation. It has an inner ring extended on both sides and is locked onto the shaft by tightening a set screw on the inner ring, making it easy to mount.

It belongs to the deep groove ball bearing, inside the rolling body for the steel ball

QUALITY DETECTION

FACTORY WORKSHOP

factory

APPLICATION FIELD

FAQ

Once the products received by customer were found not comply with the products or contract demands, what will you do?

A: We will compensate the customer for all the loss without any hesitation.

Do you provide samples Is it free or extra?

A: Yes, we could offer free samples.

What certifications do your products have?

A: We have ISO 9001, SGS, EWC and other certifications.

What kind of payment terms would you accept?

A: We always do T/T.30% T/T as deposit,70% T/T as balance.

What is the delivery time?

A: 10-15 days

What is your MOQ?

A: We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.
