PRODUCT DETAILS

Keywords: Shandong Guanxian Monten Bearing Co., Ltd.

Self-aligning performance: As the outer ring has spherical outer diameter, it can adapt to certain axial and radial deviation and reduce the influence brought by installation error.

Sealing design: with sealing rings and dust caps on both sides, it can effectively prevent dust and moisture from entering the bearing interior and prolong the service life.

Convenient installation: the inner ring is fastened by the top wire, the installation process is simple and quick.

UEL insert bearings are widely used in various mechanical equipment, especially suitable for the following scenarios:

Industrial equipment: such as jumper, terminal machines, diaphragm pumps, gear pumps, etc.

Pumps: e.g. sewage pumps, circulation pumps, spray dryers, etc.

In these application scenarios, UEL insert bearings can provide stable support and rotary function to ensure the normal operation of the equipment.

Part Number	Shaft Size d	Outside Diameter	Total Width	Static Load Rating	Dynamic Load Rating
UEL201	12 mm	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL201-8	0.5000 in	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL202	15 mm	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL202-10	0.6250 in	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL203	17 mm	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL204-12	3/4 in	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL204	20 mm	47 mm1.85 in	43.7 mm1.72 in	6650 N1495 lbf	12800 N2878 lbf
UEL205-14	7/8 in	52 mm2.047 in	44.4 mm1.748 in	7850 N1765 lbf	14000 N3147 lbf
UEL205-15	15/16 in	52 mm2.047 in	44.4 mm1.748 in	7850 N1765 lbf	14000 N3147 lbf
UEL205	25 mm	52 mm2.047 in	44.4 mm1.748 in	7850 N1765 lbf	14000 N3147 lbf
UEL205-16	1 in	52 mm2.047 in	44.4 mm1.748 in	7850 N1765 lbf	14000 N3147 lbf
UEL206-18	1 1/8 in	62 mm2.441 in	48.4 mm1.906 in	11300 N2540 lbf	19500 N4384 lbf
UEL206	30 mm	62 mm2.441 in	48.4 mm1.906 in	11300 N2540 lbf	19500 N4384 lbf
UEL206-19	1 3/16 in	62 mm2.441 in	48.4 mm1.906 in	11300 N2540 lbf	19500 N4384 lbf
UEL206-20	1 1/4 in	62 mm2.441 in	48.4 mm1.906 in	11300 N2540 lbf	19500 N4384 lbf
UEL207-20	1 1/4 in	72 mm2.835 in	51.1 mm2.012 in	15400 N3462 lbf	25700 N5778 lbf
UEL207-21	1 5/16 in	72 mm2.835 in	51.1 mm2.012 in	15400 N3462 lbf	25700 N5778 lbf
UEL207-22	1 3/8 in	72 mm2.835 in	51.1 mm2.012 in	15400 N3462 lbf	25700 N5778 lbf
UEL207	35 mm	72 mm2.835 in	51.1 mm2.012 in	15400 N3462 lbf	25700 N5778 lbf
UEL207-23	1 7/16 in	72 mm2.835 in	51.1 mm2.012 in	15400 N3462 lbf	25700 N5778 lbf
UEL208-24	1 1/2 in	80 mm3.15 in	56.3 mm2.217 in	17800 N4002 lbf	29100 N6542 lbf
UEL208-25	1 9/16 in	80 mm3.15 in	56.3 mm2.217 in	17800 N4002 lbf	29100 N6542 lbf
UEL208	40 mm	80 mm3.15 in	56.3 mm2.217 in	17800 N4002 lbf	29100 N6542 lbf
UEL209-26	1 5/8 in	85 mm3.346 in	56.3 mm2.217 in	21300 N4788 lbf	34100 N7666 lbf
UEL209-27	1 11/16 in	85 mm3.346 in	56.3 mm2.217 in	21300 N4788 lbf	34100 N7666 lbf
UEL209-28	1 3/4 in	85 mm3.346 in	56.3 mm2.217 in	21300 N4788 lbf	34100 N7666 lbf
UEL209	45 mm	85 mm3.346 in	56.3 mm2.217 in	21300 N4788 lbf	34100 N7666 lbf
UEL210-30	1 7/8 in	90 mm3.543 in	62.7 mm2.469 in	23300 N5238 lbf	35100 N7891 lbf
UEL210-31	1 15/16 in	90 mm3.543 in	62.7 mm2.469 in	23300 N5238 lbf	35100 N7891 lbf
UEL210	50 mm	90 mm3.543 in	62.7 mm2.469 in	23300 N5238 lbf	35100 N7891 lbf
UEL210-32	2 in	90 mm3.543 in	62.7 mm2.469 in	23300 N5238 lbf	35100 N7891 lbf
UEL211-32	2 in	100 mm3.937 in	71.4 mm2.811 in	29400 N6609 lbf	43400 N9757 lbf
UEL211-34	2.1250 in	100 mm3.937 in	71.4 mm2.811 in	29400 N6609 lbf	43400 N9757 lbf
UEL211	55 mm	100 mm3.937 in	71.4 mm2.811 in	29400 N6609 lbf	43400 N9757 lbf
UEL211-35	2 3/16 in	100 mm3.937 in	71.4 mm2.811 in	29400 N6609 lbf	43400 N9757 lbf
UEL212-36	2 1/4 in	110 mm4.331 in	77.8 mm3.063 in	36200 N8138 lbf	52400 N11780 lbf
UEL212	60 mm	110 mm4.331 in	77.8 mm3.063 in	36200 N8138 lbf	52400 N11780 lbf
UEL212-39	2 7/16 in	110 mm4.331 in	77.8 mm3.063 in	36200 N8138 lbf	52400 N11780 lbf
UEL213-40	2 1/2 in	120 mm4.724 in	85.7 mm3.374 in	40100 N9015 lbf	57200 N12859 lbf
UEL213	65 mm	120 mm4.724 in	85.7 mm3.374 in	40100 N9015 lbf	57200 N12859 lbf
UEL214-44	2 3/4 in	125 mm4.921 in	85.7 mm3.374 in	44100 N9914 lbf	62200 N13983 lbf
UEL214	70 mm	125 mm4.921 in	85.7 mm3.374 in	44100 N9914 lbf	62200 N13983 lbf
UEL215-47	2 15/16 in	130 mm5.118 in	92.1 mm3.626 in	48300 N10858 lbf	67400 N15152 lbf
UEL215	75 mm	130 mm5.118 in	92.1 mm3.626 in	48300 N10858 lbf	67400 N15152 lbf
UEL215-48	3 in	130 mm5.118 in	92.1 mm3.626 in	48300 N10858 lbf	67400 N15152 lbf

SA Series Insert bearing is a high quality spherical plain bearing,

QUALITY DETECTION

FACTORY WORKSHOP

factory

APPLICATION FIELD

FAQ

Once the products received by customer were found not comply with the products or contract demands, what will you do?

A: We will compensate the customer for all the loss without any hesitation.

Do you provide samples Is it free or extra?

A: Yes, we could offer free samples.

What certifications do your products have?

A: We have ISO 9001, SGS, EWC and other certifications.

What kind of payment terms would you accept?

A: We always do T/T.30% T/T as deposit,70% T/T as balance.

What is the delivery time?

A: 10-15 days

What is your MOQ?

A: We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.
